Description
Honda’s V-twin range of engines are the cream of the crop, powering pressure washers, water pumps and commercial lawn and garden equipment across Australia.
The GX690 V-twin can also be found in tillers and cultivators and other agricultural equipment, generators and many other applications.
And if it’s something more demanding that you need power for, the GX690 is also used in the forestry and construction and industrial industries.
Specifications
| Model | GX690 |
|---|---|
| Type | Air-cooled 4-stroke OHV petrol engine, 90° V-twin design, horizontal shaft |
| Bore & stroke | 2 / 78 x 72 mm |
| Displacement | 688 cm³ |
| Compression ratio | 9.3:1 |
| Net power | 16.5 kW (22.1 HP) / 3,600 rpm |
| Continuous rated power | 11.5 kW (15.4 HP) / 3,000 rpm; 13.0 kW (17.4 HP) / 3,600 rpm |
| Maximum net torque | 48.3 Nm / 4.93 kgfm / 2,500 rpm |
| Ignition system | Digital CDI with variable ignition timing |
| Starting system | Electric starter |
| Fuel consumption at rated power | 6.7 L/hr – 3,600 rpm |
| Recommended fuel | Unleaded |
| Lubrication system | Full-pressure |
| Oil capacity | 1.9 l |
| Fuel capacity | n/a |
| Dimensions | 429 x 410 x 438 mm (T-type) |
